Once the UV source or the measuring equipment moves, the dose is no longer a single reading but an integral along a path with varying distance and angle of incidence. These pages show how irradiance becomes a monitored process variable and how robot paths are designed by dose.

UV LED module above circuit boards on a cycled production line, next to it a process monitor with status display and the icons automate, integrate, monitor and reliable UV processes – UV automation and process integration

Automation

Measurand: irradiance as a PLC signal (4–20 mA, Ethernet, digital)

UV process integration embeds radiation sources and measurement into automated production so that the dose becomes a monitored process variable. The article describes the path from sensor signal to process release.

Robot arm with a UV LED tool above parts on a conveyor, next to it a monitor showing AI vision inspection and the icons automate, AI-powered, precise processes and higher efficiency – UV robotics with AI

Robotics

Measurand: dose as a path integral, irradiance versus distance and angle

UV robotics guides radiation sources or measurement with a robot – as a flange tool, as payload or by handling the part. The article shows how the dose emerges as an integral along a path with varying distance.
